Material: Hot-Dip Galvanized Steel Per ASTM A153 & CSA G164 (REPLACE XX WITH LENGTH)
| 2-1/2'' Hub 10,000#Single Helix |
| Part # |
Rod |
Flight |
| inch |
inch |
| PIA105808 |
5/8 |
8 |
| PIA100108 |
3/4 or 1 |
8 |
| PIA105810 |
5/8 |
10 |
| PIA100110 |
3/4 or 1 |
10 |
| PIA105812 |
5/8 |
12 |
| PIA100112 |
3/4 or 1 |
12 |
| PIA100114 |
3/4 or 1 |
14 |
| 2-1/4'' Hub 8,000# Single Helix |
| Part # |
Rod |
Flight |
| inch |
inch |
| PIA85808 |
5/8 |
8 |
| PIA80108 |
3/4 or 1 |
8 |
| PIA85810 |
5/8 |
10 |
| PIA80110 |
3/4 or 1 |
10 |
| PIA85812 |
5/8 |
12 |
| PIA80112 |
3/4 or 1 |
12 |
| PIA80114 |
3/4 or 1 |
14 |
| 1-3/8'' Shaft 6,000# Single Helix |
| Part # |
Rod |
Helix |
| inch |
inch |
| PIA658XX08 |
5/8 |
8 |
| PIA601XX08 |
3/4 or 1 |
8 |
| PIA658XX10 |
5/8 |
10 |
| PIA601XX10 |
3/4 or 1 |
10 |
| PIA658XX12 |
5/8 |
12 |
| PIA601XX22 |
3/4 or 1 |
12 |
| PIA601XX14 |
3/4 or 1 |
14 |
| 1-1/2'' Shaft 7,000# Single Helix |
| Part # |
Rod |
Helix |
| inch |
inch |
| PIA758XX08 |
5/8 |
8 |
| PIA701XX08 |
3/4 or 1 |
8 |
| PIA758XX10 |
5/8 |
10 |
| PIA701XX10 |
3/4 or 1 |
10 |
| PIA758XX12 |
5/8 |
12 |
| PIA701XX12 |
3/4 or 1 |
12 |
| PIA701XX14 |
3/4 or 1 |
14 |
| 1-1/2'' Shaft 7,000# Double Helix |
| Part # |
Rod |
Helix |
| inch |
inch |
| PIA701XX4-4 |
1 |
4-4 |
| PIA701XX8-8 |
1 |
8-8 |
| PIA701XX10-10 |
1 |
10-10 |
| 1-3/8'' Shaft 6,000# Double Helix |
| Part # |
Rod |
Helix |
| inch |
inch |
| PIA601XX4-4 |
1 |
4-4 |
| PIA6018XX-8 |
1 |
8-8 |
| PIA601XX10-10 |
1 |
10-10 |
| Power Installed Anchor Rods |
| Part # |
Size |
Length |
Tensile
Strength |
| inch |
inch |
| PIAR5842 |
5/8 |
42 |
16.000# |
| PIAR3442 |
3/4 |
42 |
23.000# |
| PIAR0142 |
1 |
42 |
36.000# |
| PIAR5884 |
5/8 |
84 |
16.000# |
| PIAR3484 |
3/4 |
84 |
23.000# |
| PIAR0184 |
1 |
84 |
36.000# |
| Power Installed Nuts |
| Part # |
Rod |
Eye |
| inch |
| PIAN581 |
5/8 |
Thimble |
| PIAN011 |
3/4 or 1 |
Thimble |
| PIAN582 |
5/8 |
Twin |
| PIAN012 |
3/4 or 1 |
Twin |
| PIAN583 |
5/8 |
Triple |
| PIAN013 |
3/4 or 1 |
Triple |
| Rod Couplers |
| Part # |
Size |
Desc. |
Weight |
| inch |
| PIAC58 |
5/8 |
Coupler |
0.50 |
| PIAC01 |
3/4 - 1 |
Coupler |
0.50 |
